evertz DreamCatcher - 3 Configuration; Network Configuration; Dreamcatcher Server Network Configuration; Figure 3-1: Server Configuration Login

DreamCatcher Replay System
Page 18 Revision 1.13
3. CONFIGURATION
3.1. NETWORK CONFIGURATION
3.1.1. DreamCatcher Server Network Configuration
 Use Figure 2-1 as reference.
 Ensure DreamCatcher is powered off.
 Connect a USB keyboard into one of the 4 USB ports at the back of DreamCatcher.
 Connect a monitor into the DVI connector at the back of DreamCatcher.
 Power on DreamCatcher by pressing the power button located at the top right front of DreamCatcher.
 Once DreamCatcher has fully booted and settled on the layout screen press CTRL-ALT-F2 on the
keyboard.
 You should now see the login prompt on Figure 3-1.

Figure 3-1: Server Configuration Login
 Type “admin” for a login and “admin” for a password when prompted
 You should now see the following configuration menu shown in Figure 3-2.
Figure 3-2: Configuration Menu
