remain the bottom two DIN. The most that can be done are 10in x 4out in a HD setup, and 8in x 2out on
1080P setup, Using 2-4, follow these general rules for cabling inputs and outputs.
Connect output 1 to the DIN connector immediately adjacent to the reference signal connector. In
Figure 2-10 this would be the second DIN from the bottom.
IMPORTANT: You will need both Reference DINS (Left and Right) plugged in. Also,
ensure that 1 of the XLR connections on each breakout cable are connected
to get timecode.
The remaining outputs will connect incrementally following output 1.
Figure 2-10: High Density DIN Connectors
