EMC-DCP
EMC DESKTOP CONTROL PANEL
Page 2 Revision 1.1
2. INSTALLATION OF EMC-DCP
2.1. UNPACKING
Carefully remove the equipment from the boxes and check against the Packing List supplied with each
unit. This shows what items have been shipped against your order and includes all options. Any error
should be reported to your supplier immediately. After you have unpacked the equipment please save
all the packing material as this could be useful in the future if the unit needs to be returned for
maintenance.
Check each item supplied for transit damage. Any damage should be reported in detail to your supplier.
You must state the serial number of the unit (to be found on the rear or side of each unit).
The EMC-DCP is shipped with the following pieces of equipment:
Part Description Quantity
Optional 4.3” LCD panel installed (if +LCD was ordered)
Optional 15 LCD buttons panel with 5 shaft encoders installed (if +ABP was
ordered)
Optional EMC-DCP-RP for panel angle adjustments
LED Button transparency sheet
Table 2-1: Packing List
If items are missing from the EMC-
DCP, please contact Evertz Service department
at 1-905-335-7570 or service@evertz.com.
2.1.1. Physical Location
The control panel is normally mounted on a desktop or in a console; however it may also be mounted in
a sliding tray of an equipment rack. If rack mounting is desired, you can remove the rack mount cover
plates on each side to expose the rack mount brackets.
2.1.2. Cooling
Overall power dissipation is relatively low but certain components run hot and cooling is provided for
these by internal fans. These draw cool air from one side of the panel and exhaust it through the other
side vents.
In all cases it is important to keep the apertures clear of obstructions e.g. cables
