evertz EMC-DCP - Power Supply Requirements

EMC-DCP
EMC DESKTOP CONTROL PANEL
Revision 1.1 Page 3
2.1.3. Power Supply
The EMC-DCP comes with an auto-ranging DC voltage adapter that automatically senses the input
voltage. Power should be applied by connecting a 3-wire grounding type power supply cord to the
power entry module on the DC voltage adapter. The power cord should be minimum 18 AWG wire size;
type SVT marked VW-1, maximum 2.5 m in length. The DC cable of the voltage adapter should be
connected to the DC power jack on the rear of the panel.
WARNING:
This equipment uses power/mains connectors fitted with safety ground pins.
To reduce the risk of electric shock, grounding of the ground pin of the mains
plug must be maintained.
To completely disconnect this equipment from the AC mains, disconnect the
power supply cord plug from the AC receptacle.
This equipment may have
more than on
e power supply cord. To reduce the risk of electric shock,
disconnect all power supply cords before servicing.
