205
POWERHEAD
POWERHEAD DISASSEMBLY
11
Remove the ball, guide, and spring of the shift
detent assembly from the crankcase.
Crankcase Disassembly
Remove screws and exhaust side water cover.
Use a 1/8 in. diameter pin punch to push crank-
case taper pin toward the front side of the engine.
Remove crankcase flange screws.
Loosen in stages and remove the main bearing
nuts and washers.
Separate crankcase and cylinder block. It may be
necessary to tap on crankshaft with a rawhide or
rubber mallet to loosen.
1. Shift detent assembly 002135
002234
WARNING
Wear safety glasses to avoid injury.
002232
1
002229
002251
002252
