8. Operation on XNet Network
8.1. Overview
The XNet Network is set up in the EVS application. For more information, on how to set
up the XNet Network and connect to the XNet network, refer to the section ‘SDTI
Network’ in the Configuration manual.
When the remote system is selected, the operation with remote clips or remote trains is
similar to the operations on the local system as described later in this chapter.
8.2. Selecting a Network Server
In the Remote Panel Interface
Press the Network key to display the following Network menu:
Select a LSM on XNETPage
1/4
F1 MICHELF6MACHINE6
F2PIERREF7MACHINE7
F3 PAULF8MACHINE8
F4 JACQUESF9MACHINE9
F5 ANDRE (LOCAL)F0MACHINE0
Previous Next
Local Clips Records Clip+Rec
The LCD screen of the Remote Panel displays the complete list of available systems on
the network.
• The list is organized according to the order of connection on the network.
• Up to 4 pages are available to display up to 31 servers.
• The Previous and Next commands appear only when all machines do not fit on the
current page.
Select one of the following 4 available connection modes (the active mode is highlighted).
These modes are detailed below.
• Local
• Clips
• Records
• Clip+Records
Once the desired mode is selected, press the F_key corresponding to the remote
system.
OPERATION MANUAL Multicam LSM 12.05
8. Operation on XNet Network 173
