2.3. Remote Panel Operations

2.3.1. Main Menu

Introduction

After the boot sequence of the Multicam system, the LCD screen of the Remote Panel

will display the Main menu:

2Rec 4PlayServerVer:11.00.xx

F1: 1 RemoteF6: Exit

F2: 2 RemotesF7: Clear all clips

F3: 3 RemotesF8: Stop Record

F4: 4 RemotesF9: Fill Playlist

F5: Char. On/OffF0: Technical setup

Split Paint Target Setup

1PGM+PRV 2 PGM

The Main menu has special function key operations as shown above, as well as the “soft”

keys options to enter 1PGM, 1PGM+PRV, 2PGM, or 3PGM modes (if available) and to

enter the Setup menu to configure your remote controller or to add special functions to

your application.

Note

If 2 channels are available for the first Remote Panel, the B key will display 2

PGM. If 3 channels are available, the B key will display 3 PGM.

Returning to the Main Menu

From any section of the application, except Playlist mode, press SHIFT+MENU on the

first Remote Control panel to return to the main menu.

Function Keys in the Main Menu

Select the corresponding Function key (F_ key), and then press ENTER to validate the

selection.

Function Key Use

F1 to F4 If desired, the Multicam system can be run using 1, 2, 3 or 4 EVS

Remote Panels. Depending on the number of play channels

available in the current configuration, 1-, 2-, 3- or 4- Remote

modes will be available from the main menu.

F1: 1 Remote One Remote Panel is used in the configuration

OPERATION MANUAL Multicam LSM 12.05

2. Working Interfaces 11
