Displayed letter Function
S Play back the clip at slow motion speed. The speed of slow motion
is predefined in the PGM Speed/Var max parameter in the
Operational Setup menu (p.9.1 F3).
P Play back the current clip at normal speed.
The clip countdown displays the field time. This means that the countdown matches the
slow motion speed.
Note
Selecting C (clear) from the monitor enters the Clear menu and the DFC menu.
This DFC menu allows you to select the brush color from a YUV color palette.
Note
If working in network mode, you can apply a Paint on remote clips as well as on
local clips.
9.1.3. Function Description
Straight Line / Broken Line Drawing (L)
To draw a line, proceed as follows:
1. Select L on the Paint mode monitor display.
2. Place the pen at the start point and press lightly to define the first point of the line.
3. Place the pen at the next point and press lightly again. A straight line appears to
connect these 2 points.
4. Repeat this as many times as necessary until the line is complete,
5. Place the pen over the 'ESC' area in the top right corner of the OSD and press lightly.
The system automatically defaults back to Freehand Drawing mode.
OPERATION MANUAL Multicam LSM 12.05
9. Advanced Control Modes 183
