9.3.3. Commands Description
The following commands are available on the Remote Panel to control and manage the
Offside Line option:
Main Menu
The offside line menu displays as follows while the Mark key is blinking:
TRANSP OSD QUIT
SHIFT SIDE REDO UNDO
The available commands are:
OSD Command Key Meaning
SHIFT/TILT A Moves the line horizontally (shift) or around its pivot
point (tilt).
SIDE B Changes the shaded area from side.
REDO C Redoes the last undone action (you can redo the last
10 undone actions).
UNDO D Undoes the last action (you can undo the last 10
actions).
TRANSP SHIFT+B Allows the user to change the transparency level with
the jog or lever. Press Enter to validate the action.
OSD SHIFT+C Allows the user to hide or display again the
information on the OSD.
QUIT SHIFT+D Exits the offside line mode.
Secondary Menu
Press the MENU key to open the secondary menu and specify the following offside line
settings:
Setting Description
Pause duration Time (in frames) between the train or clip is paused and the
offside line mark is displayed.
Fade in/out duration Duration (in frames) of the fading effect on the IN and OUT
points of the offside sequence.
Preroll duration Preroll (in seconds) before the offside sequence
automatically defined as a cue when the sequence is saved.
194 9. Advanced Control Modes
EVS Broadcast Equipment SA Issue 12.05.A- May 2014
