EVS Multicam LSM User Manual

Local
Rst Cam Local Sync Prv 2nd CTRL
Cam A Cam B Cam C Cam D
This function allows the user to reconnect to the local LSM after having accessed distant
clips or record trains. The function is highlighted when the user is connected to both clips
and record trains on the local LSM. It is displayed only on Master/Server LSMs when they
are connected to the SDTI network.
Sync Prv
Rst Cam Local Sync Prv 2nd CTRL
Cam A Cam B Cam C Cam D
This option allows the user to synchronize the PRV with the timecode and speed of the
PGM output. This function is not available with remote record trains.
2nd CTRL
Rst Cam Local Sync Prv 2nd CTRL
Cam A Cam B Cam C Cam D
This function allows the operator to swap the control of one or several play channels
between the EVS Remote and a third-party controller. Both controllers receive
permanently the status of the channel(s), but only one controller at a time is able to
actually control a channel. The secondary controllers are defined in page T2.2 of the
Technical Setup menu.
Press this function to enter the 2ndCTRL menu, select the channels that you want to
pass to the secondary controller by pressing the corresponding A or B key, then press D
(DONE) to validate your selection. Do the same to bring the control of a channel back to
the EVS remote.
See section "Secondary Controller" on page 33.
3.2.3. 1PGM+PRV Secondary Menu Controls
Introduction
The secondary menu in 1PGM+PRV mode, illustrated below, gives access to the
functions detailed in the following paragraphs:
Aud.Met. PgmSpd Sort->TC PostRoll
Mix. Sw to IN Search Pref
24 3. Control Modes
EVS Broadcast Equipment SA Issue 12.05.A- May 2014
