Screen Description
Commands Description
Command Description
V SPLIT / H SPLIT Toggles between horizontal and vertical Split screen menus
Swap To swap sources from both sides
Sync To synchronize the selected PGM with the other one. Press
this button and select the PGM to use as a reference.
Top To control the upper part of the monitor
Bottom To control the lower part of the monitor
T & B To control both sides together
SHIFT Access / Exit special commands
<–Tp–> To center the top picture
<–Bt–> To center the bottom picture
<–WP–> To move the separation line
• Press the Top key to take control of the upper side of the screen, and recall the
desired clip for this side. Use the command knob to search inside the clip until the
desired picture is reached.
• Press the Bottom key to take control of the lower side of the screen, and repeat the
same operation with the clip you want to display on this side.
• You can also shift vertically the clips on both sides, so that the action is in the centre
of the picture.
• Press the SHIFT+D to enter this mode. The menu will change, as shown above.
200 9. Advanced Control Modes
EVS Broadcast Equipment SA Issue 12.05.A- May 2014
