EX-2001 NC RACER ZSME300000091
24
EXCELL PRECISION CO., LTD.
2 Refer to Chapter 9 Function Table to set FUNC. 60 ~ FUNC. 69
2 Transmit format
Format 1
S T , G S , + 1 2 3 4 . 5 6 g CR LF
Header 1 Header 2 Weight Data ( 8 digits ) Units Terminators
Format 2
STX
1 2 . 3 4 K G CR LF
Initial code Weight Data ( 8 digits ) Unit Status Terminators
Format 3
S T , G S , + 1 2 . 3 4
g CR LF
Header 1 Header 2 Weight Data ( 8 digits ) Unit Terminators
Format 4
S T , G S , + 1 2 . 3 4 g CR LF
Header 1 Header 2 Weight Data ( 8 digits ) Unit Terminators
Header 1
ST : Stable / US : Unstable / OL : Over Load
Header 2
GS : Gross weight / NT : Net weight / TR : Tare
Weight Data ( 8 digits )
Format 1
The first digit is the “+ / -” symbol for weight value. The next seven digits include decimal
point and weight value. When the weight is over loaded (Header 1 : OL), all digits will be
transmitted “blank” (sp) except the “+ / -“ signal and the decimal point.
Format 2
The first digit is the “+ / -” symbol for weight value. “+” symbol will display “blank”. The
next seven digits include decimal point and weight value. When the value is inefficacy, all
digits will be transmitted “blank”.
Format 3 ~ 4
The first digit is the “+ / -” symbol for weight value. The next seven digits include decimal
point and weight value. When the value is inefficacy, all digits will be transmitted “blank”.
