OP-01 RS-422 / RS-485 ，OP-06 / OP-07 RS-232 INTERFACE FUNCTION
SET VALUE
FUNC. NO. FUNCTION
PARAMETER DESCRIPTION
DEFAULT
0 As displayed
1 Gross
2 Net
FUNC. 60 Data type
3 Tare
0
0 Stream transmit
1 Auto-transmit
2
Press the key to transmit
3 Command mode (without address)
FUNC. 61 Transmit mode
4 Command mode (with address)
0
0 1 200
1 2 400
2 4 800
FUNC. 62 BAUD rate
3 9 600
1
0 N, 8, 1
No parity bit,
8 data bit, 1 stop bit
1 O, 7, 1
Odd parity bit,
7 data bit, 1 stop bit
FUNC. 63
Parity bit
Data bit
Stop bit
2 E, 7, 1
Even parity bit,
7 data bit, 1 stop bit
2
0 None
1 kg
2 g
3 t
FUNC. 64 Units
4 lb
1
0 Continuous output
FUNC. 65
Unstable or
over the max.
capacity
1 Stop output
0
0 Positive (more than + 5D)
FUNC. 66
Auto-transmit
conditions
1
Positive / negative (more than + 5D,
less than - 5D)
0
FUNC. 67
Command
address
00
↓
99
When the FUNC. 61 is set in 4, it will
use this address
0
0 Format 1
1 Format 2
2 Format 3
FUNC. 68 Output format
3 Format 4
0
0 Unlimited
1 1 time/s
2 2 times/s
3 5 times/s
4 10 times/s
FUNC. 69
Transmit
frequency
5 20 times/s
4
0 Stop RS-422/485
FUNC. 70 Output type
1 Start RS-422/485
0
PRINT
