Excell NC RACER EX-2001 User Manual

EX-2001 NC RACER ZSME300000091
44
EXCELL PRECISION CO., LTD.
OP-02 BCD OUTPUT INTERFACE FUNCTION
SET VALUE
FUNC. NO. FUNCTION
PARAMETER DESCRIPTION
DEFAULT
0 As displayed
1 Gross
FUNC. 80 Data type
2 Net
0
0 Stream transmit
1 Auto-transmit
FUNC. 81 Transmit mode
2
Press the key to transmit
0
0 Positive logic
FUNC. 82
Output data
logic
1 Negative logic
0
0 Positive logic
FUNC. 83 Signal logic
1 Negative logic
0
OP-03 ANALOGUE OUTPUT INTERFACE FUNCTION
SET VALUE
FUNC. NO. FUNCTION
PARAMETER DESCRIPTION
DEFAULT
0 As displayed
1 Gross
FUNC. 85 Data type
2 Net
0
FUNC. 86
Low point of
weight value
000 000
↓
999 999
0
FUNC. 87
Low point of
output current
value
0.0 mA
↓
20.0 mA
When the weight value
reaches the value set in
FUNC. 86, the current output
is the value set in FUNC. 87
4.0 mA
FUNC. 88
High point
Weight value
000 000
↓
999 999
16 000
FUNC. 89
High point
Output current
value
0.0 mA
↓
20.0 mA
When the weight value
reaches the value set in
FUNC. 88, the current output
is the value set in FUNC. 89
20.0 mA
PRINT
