Inspecting Fiber Ends
88 FIP-400B
Analyzing Captures
3. Tap at the end of the Inspection Results row.
4. From the Inspection Results window, you can select another fiber you
want to view by tapping on its number.
5. Tap Done to return to the Results window.
Dual-row multifiber connector
Single-row
multifiber
connector
