Expert Sleepers Disting mk4 - D-6 Low Pass;Band Pass Filter; D-7 Band Pass;High Pass Filter; D-8 Band Pass;Notch Filter

D-6 LP/BP Filter
Video
X is audio input
Y is filter frequency
Z is filter resonance
A is low pass filter output
B is band pass filter output
Parameter Min Max Default Description
0 -80 80 0 Y Offset.
This is a filter with simultaneous low pass and band pass outputs.
X is the audio input.
Y sets the filter frequency, with a 1V/octave response. The 0V point is C3 (approximately
130.81Hz). Parameter 0 is added to the Y CV; its range of ±80 corresponds to ±5V.
Z controls the filter resonance.
D-7 BP/HP Filter
Video
X is audio input
Y is filter frequency
Z is filter resonance
A is band pass filter output
B is high pass filter output
Parameter Min Max Default Description
0 -80 80 0 Y Offset.
This is a filter with simultaneous band pass and high pass outputs.
X is the audio input.
Y sets the filter frequency, with a 1V/octave response. The 0V point is C3 (approximately
130.81Hz). Parameter 0 is added to the Y CV; its range of ±80 corresponds to ±5V.
Z controls the filter resonance.
D-8 BP/Notch Filter
Video
X is audio input
Y is filter frequency
Z is filter resonance
A is band pass filter output
B is notch filter output
Parameter Min Max Default Description
0 -80 80 0 Y Offset.
This is a filter with simultaneous band pass and notch outputs.
Page 43
