Value Y mode Description
0 Not used. The X clock is taken to start as soon as pulses appear on the X
input, and is assumed to have stopped if no pulses appear for two
seconds.
1 Run/stop for X. The X clock is ignored until Y goes high (over 1V) and stops when
Y goes low.
2 Run/stop for internal. The internal clock starts when Y goes high and stops when Y goes
low.
3 Run/stop for both. Both the X clock and the internal clock are controlled by Y as
above.
Parameter 7 enables "ratcheting" - a CV controllable clock multiplier. This can be enabled for
outputs A, B, or both, and can multiply by powers of 2 only (1, 2, 4, 8, 16), or by multiples of 2 and
3 (1, 2, 3, 4, 6, 8, 12, 16).
Parameter value Ratchet mode A Ratchet mode B
0 Off Off
1 2's Off
2 Off 2's
3 2's 2's
4 2's/3's Off
5 Off 2's/3's
6 2's/3's 2's/3's
When enabled, the Z input/pot controls the multiplier. When Z is at 0V, the clock output is
suppressed; higher voltages give higher multipliers. If you prefer a 0V CV input to correspond to 1x
multiplier instead of stopping the clock, simply turn Z slightly clockwise to bias the input positive.
G-7 MIDI/CV
Video
X & Y are not used
A is pitch CV output
B is gate output
Z is not used
Receives MIDI
Parameter Min Max Default Description
0 -48 48 0 Transpose.
1 0 24 2 Pitch bend depth.
2 -1 99 -1 Scale.
3 0 32 0 Portamento.
4 0 100 0 Interrupt.
5 0 2 0 Priority.
6 0 1 0 Mode.
