Performs a MIDI to CV conversion on MIDI notes arriving on the disting's MIDI port.
The received MIDI channel is selected in the settings.
Parameter 6 sets the mode of operation.
Parameter value Mode description
0 Output A is the pitch CV output; output B is the gate output.
1 Output A is the pitch CV output; output B is another pitch CV output using
the next MIDI channel up.
2 Output A is the pitch CV output; output B is a velocity gate output.
Outputs A & B can also be controlled directly via MIDI CCs according to the following table:
CC numbers (A/B) Output voltage range
33/34 -5V to +5V
35/36 0V to 10V
37/38 0V to 5V
39/40 0V to 8V
Parameter 2 selects a scale to use, if any are provided on the SD card. See “Scala Support” above.
The default value of -1 disables this function.
Parameter 3 enables a 'fingered portamento' effect, that is, a glide from one note to the next if they
are played legato. Higher parameter values give a slower glide.
Parameter 4 enables an interruption of the gate output when notes are played legato. The parameter
value sets the time in milliseconds to send the gate low when a new note is played.
Parameter 5 sets the note priority mode. The options are Last, Low, and High.
Page 64
