Expert Sleepers Disting mk4 - H-7 Noise Generator

Parameter 0 controls the function of Z:
Parameter 0 value Z function
0 Z controls delay
1 Z controls length
2 Output override (high). Z over 1V forces both outputs high.
3 Output override (low). Z over 1V forces both outputs low.
4 Input enable. Z below 1V disables input triggers.
5 Input disable. Z above 1V disables input triggers.
6 Z is an additional trigger input which triggers both outputs.
H-7 Noise
Video
A is noise, optionally scaled by X
B is noise, optionally scaled by Y
Z is blend
Parameter Min Max Default Description
0 -1 3 -1 Type A.
1 -1 3 -1 Type B.
2 -1 31 31 Attenuation A.
3 -1 31 31 Attenuation B.
Dual output variable-colour noise generator, with two optional VCAs.
Outputs A and B are noise, with colour according to the parameter values:
Parameter value Noise colour
-1 Blended
0 Violet
1 White
2 Pink
3 Red
If 'blended' is chosen, the noise colour can be smoothly swept from violet to red with the Z
knob/CV.
Parameters 2 & 3 set the attenuation of the outputs (31 corresponds to ±8V output for white noise).
If the parameter is set to -1, the corresponding X/Y input is used to set the output amplitude
(equivalent to following the noise output with a VCA driven by X/Y). The X/Y inputs are clamped
at 0V i.e. negative input voltages yield silence.
Page 72
