G-8 CV/MIDI
Video
X is pitch CV input
Y is gate input
A & B pass through X & Y
Z is mod wheel or velocity CV input
Outputs MIDI
Parameter Min Max Default Description
0 0 99 16 Channel offset.
1 -127 127 0 Z mode.
2 -99 99 0 X CC.
3 -99 99 0 Y CC.
Generates MIDI notes (on the MIDI channel selected in the settings) from the pitch and gate CVs
on the X & Y inputs.
Parameter 0 sets an offset between the timing of the X & Y inputs (in sample frames). It is generally
a good idea to delay the pitch slightly relative to the gate, to ensure that the pitch has changed and
settled before the gate triggers a new note.
Parameter 1 chooses the function of the Z knob/CV. If 0, Z sets the velocity of the generated MIDI
notes. Otherwise, Z generates CC messages using the parameter value as the CC number, and the
note velocity is fixed at 64.
Parameters 2 & 3, when non-zero, allow you to generate CC messages from the X & Y inputs
(using the parameter value as the CC number).
For parameters 1, 2 & 3, whether the parameter is positive or negative sets the working voltage
range. For positive parameter values, the voltage range 0-5V generates the full range of CCs (0-
127). For negative parameter values, the voltage range ±5V is used.
If Y is to be converted to a CC, then notes are no longer generated.
H-1 Crossfade/Pan
Video
A = Mix of X & Y according to Z
B = Inverted mix of X & Y according to Z, or LFO
Knob recorder enabled
Parameter Min Max Default Description
0 0 3 0 Crossfade/pan law.
1 0 2 0 Clip mode.
2 -1 99 0 Output B option/LFO speed.
3 0 32 32 Output B attenuation.
Viewed as a stereo output, A & B provide a panned version of X, plus an oppositely panned version
of Y.
