Video
X is clock
Y is retrigger CV
Z selects the MIDI file
A is pitch CV output
B is gate output
Outputs MIDI
Parameter Min Max Default Description
0 -1 31 -1 Selects the MIDI file.
Algorithm-specific playlist filename: midi-playlist-clocked.txt
This algorithm plays MIDI files, converting the MIDI into CV outputs on A & B (as detailed
above).
The current MIDI file is selected with the Z knob/CV, if parameter 0 is -1, or by the parameter itself
if it is in the range 0-31, in which case Z is not used.
The X input is a clock, which controls the speed of the MIDI file playback. A clock pulse should
exceed 1V. The clocks correspond to quarter notes in the MIDI file.
Y is a retrigger input. A trigger pulse in excess of 1V will reset the file to the beginning.
MIDI Output: the MIDI file being played is transmitted unaltered on the disting's MIDI output.
J-2 Multisample 2 Audio Playback
Video
X is retrigger CV
Y is V/octave pitch CV
Z is tune ±0.5 octaves
A is left audio output
B is right audio output
Parameter Min Max Default Description
0 0 99 0 Folder.
1 -8 8 0 Octave shift.
2 0 99 0 Envelope time.
3 -1 4 -1 MIDI mode.
4 0 24 2 Pitch bend depth.
5 0 1 1 Selects the panning option.
6 0 60 0 Gate offset.
This algorithm plays audio files, using a 1V/octave pitch input (Y) to both select the sample and
control its pitch. This would typically be used for playing a multisampled instrument across a range
of pitches, or for mapping individual sounds (e.g. drums) to different notes.
This is a dual version of the Multisample Audio Playback algorithm below. Two voices play at
once; they can play continuously, but a more typical use would be to use the envelope time
parameter to have notes decay when the gate closes – then, this being a dual algorithm, one note can
continue to decay while the next one starts.
Page 82
