G-1 ES-1 Emulation
Video
X is input 1
Y is input 2
Z is trim
A is output 1
B is output 2
This algorithm provides a software implementation of the Expert Sleepers ES-1 module. This in
conjunction with the Silent Way AC Encoder plug-in this allows you to pass CVs from your DAW
to your modular via an AC coupled audio interface.
X & Y are the two inputs - connect these to outputs from your audio interface.
A & B are the corresponding outputs - connect these to CV inputs in your modular.
Z provides a trim control. Adjust this so that a zero CV entering the AC Encoder plug-in gives you
a zero CV out of the disting (either with a voltmeter, or by eye, just looking at the colour of the
disting's output jacks).
G-2 ES-2 Emulation
Video
X is input 1
Y is input 2
Z is trim
A is output 1
B is output 2
This algorithm provides a software implementation of the Expert Sleepers ES-2 module. This in
conjunction with the Silent Way CV Input plug-in this allows you to pass CVs from your modular
into your DAW via a regular audio interface.
X & Y are the two inputs - connect these to CV outputs from your modular.
A & B are the corresponding outputs - connect these to inputs on your audio interface.
Z provides a trim control, allowing adjustment of the ES-2's operating frequency. Start with this at
zero (LEDs off) and adjust to minimise noise in the CV recovered from the plug-in.
G-3 Pitch Reference
Video
X & Y are not used
A is sine output
B is square output
Z sets the amplitude of A & B
Parameter Min Max Default Description
0 0 11 0 Semitone.
1 -1 9 4 Octave.
Generates sine and square waves at a fixed pitch, specified by the parameters.
