Turntable control SmartTurn
Installation and commissioning
44 Dok-ID:EXPERT-0003-EN-2011
Pos: 5.13 /S martT ur n/S mar tTur n-Neu-0 2.2 011/ 5.3. 2_b An schl üss e St euer tei l @ 3\mod_1297858059196_38.doc @ 26178
Connections control unit
Fig. 18 SmartTurn outputs
 A: PLC plant controller
 B: SmartTurn control unit
 K: „0-position"
 L: “Overrun forward"

M: “Overrun back"
 N: "System fault"
 P: „End lock angle"
 O: "Operating mode"
 R: „Position back"

T: "In the lock angle"
