Expert SmartTurn - Page 48

Turntable control SmartTurn
Installation and commissioning
48 Dok-ID:EXPERT-0003-EN-2011
Special mode
Sequence special mode 1 cycle / 2 cycles
Switch S1 in position 9
Number of cycle:
Function Signal Pin
Operating mode
E4
7
Pre-select cycles
bit 1
E5
16
Pre-select cycles
bit 2
E6
18
Forward on
E1
1
Forward start
A1
2
Backward on
E2
3
Backward start
A2
4
Slow on
E3
5
0-position
A3
8
Position forward
A8
14
Position back
A9
15
In the lock angle
A10
17
System fault
A6
11
Motor is turning
Position
1 cycle forward 2 cycles backward 1 cycle backward 2 cycles forward
Fig.
22 Sequence graphic – special mode
