▪ Carefully pull out the spare cable for the microphone and charger from the hull, then set the
panel aside as depicted in the image below.
▪ Remove the two socket button head screws that secure the robot's upper front panel and set
the panel aside.
▪ Remove the eight screws that secure the battery pack's lid and set it aside.
