Table 17: Cable Distances and Types (continued)
Standard Media Type MHz•km
Rating
Maximum Distance
(Meters)
100BASE-TX Category 5 and higher UTP cable – 100
10BASE-T Category 3 and higher UTP cable – 100
Table 18 and Table 19 on page 47 list direct-attach cables available from Extreme Networks.
Table 18: Extreme Networks 100Gb Direct-Attach Cables
Cable Type Part Number Length
QSFP28-QSFP28 Direct attach passive copper cable 10411 or AA1405029-
E6
1 meter
10413 or AA1405031-
E6
3 meters
10414 or AA1405032-
E6
5 meters
QSFP28-4xSFP28 (4x25Gb) Direct attach passive
copper breakout
10421 1 meter
10423 3 meters
10424 5 meters
QSFP28-4xSFP28 (4x25Gb) Active optical breakout
cable
10444 20 meters
Table 19: Extreme Networks 40Gb Direct-Attach Cables
Cable Type Part Number Length
QSFP+ to QSFP+ Direct attach cable AA1404037-E6 0.5 meter
AA1404029-E6 1 meter
AA1404030-E6 2 meters
AA1404031-E6 3 meters
AA1404032-E6 5 meters
QSFP+ to QSFP+ Active optical cable AA1404028-E6 10 meters active
optical
QSFP+ to 4xSFP+ Breakout cable AA1404033-E6 1 meter
AA1404035-E6 3 meters
AA1404036-E6 5 meters
AA1404041-E6 10 meters active
optical
Site Preparation Installing Cable
ExtremeSwitching 5520 Series Hardware Installation Guide 47
