DXP HD 4K PLUS Series • Internal Web Page 101
Firmware Panel
The Firmware panel (see figure54,
8
, on page 93) displays the current firmware version
and the date it was last updated. You can also update the firmware on your DXP from
this panel (firmware files can be downloaded from www.extron.com, see Downloading
Updated Firmware starting on page103).
To update the firmware on your DXP:
1. In the Firmware panel, click the Select File button.
2. In the Open dialog box, browse to locate the new firmware file on your computer (by
default the file is stored at C:\Program Files (x86)\Extron\Firmware after being
downloaded from the Extron web page).
NOTE: Firmware files for DXP HD 4K PLUS series have a .eff extension. Do not
attempt to load any other file types.
3. Double-click the firmware file name. The Open window closes, and the selected
firmware file name appears in the Update Firmware panel on the web page (see
figure 62,
1
).
Figure 62. Firmware Update Dialog Box with a Firmware File Selected
4. Click Update to begin (
2
). (If you want to cancel the update, click the X button in the
upper-right corner of the Update Firmware panel.)
During the updating process, a window appears in the middle of the screen, showing
the progress of the update: Uploading, Initializing, Writing to Flash, and
Rebooting (see figure 63).
Figure 63. Firmware Update Progress Window
When the update is completed, the progress window closes and the message
Firmware Upload Complete appears near the top of the screen. The new firmware
filename appears beside Version in the Firmware panel of the web page.
62
63
