DXP HD 4K PLUS Series • SIS Configuration and Control 48
Command and Response Table for SIS Commands — DXP 44, 84, 88
Command ASCII Command
(Host to Switcher)
Response
(Switcher to Host)
Additional Description
Input and Output Tie Commands
Individual Ties
Tie HDMI input to HDMI and
audio outputs
X!*X@! OutX@•InX!•All]
Tie or untie an HDMI video
input with embedded audio
to an HDMI output (analog
or S/PDIF) with the extracted
audio.
NOTE: All HDMI source signals switch with embedded audio.
Example: Breaking a tie
0*2! Out2 In0 All
Untie an HDMI video input
with embedded audio from the
HDMI output.
Tie HDMI input to HDMI output
X!*X@ % or
X!*X@&
OutX@•InX!•Vid]
Tie or untie an HDMI input to
an HDMI output.
Tie HDMI audio input to audio
only output (audio output 2 only)
X!*X@ $ OutX@•InX!•Aud]
Tie or untie an HDMI audio
input to an analog audio and
S/PDIF output (audio output 2
only).
Ties from an Input to All Outputs
Tie HDMI input to all HDMI and
audio outputs
X!*! InX!•All]
Tie an HDMI input to all HDMI
and audio outputs.
Tie HDMI input to all HDMI
outputs
X!*% or
X!*&
InX!•Vid]
Tie an HDMI input to all HDMI
outputs.
Tie HDMI audio input to all audio
only outputs (audio output 2 only)
X!*$ InX!•Aud]
Tie an HDMI audio input to
all analog audio and S/PDIF
outputs (audio output 2 only).
Quick Tie
Multiple ties
E+QX!*X@ %...X!*X@!} Qik]
(& can be substituted for %.)
Make multiple ties in one
command entry (applies to
HDMI and audio outputs).
Example (DXP 88 HD 4K
PLUS)
E+Q3*4%6*1$3*2!} Qik]
(& can be substituted for %.)
Tie HDMI input 3 to HDMI
output 4, HDMI audio input 6
to analog audio output 1, and
HDMI input 3 to HDMI and
analog audio output 2.
KEY:
X! = Input number
0 = untie (for ties If applicable)
1 through <maximum number of inputs>
X@ = Output number
0 = untie (for ties if applicable)
HDMI output, 1 through <maximum number of outputs>:
DXP 42 — 1 or 2, DXP 44 and 84 — 1-4, DXP 88 — 1-8
