DXP HD 4K PLUS Series • SIS Configuration and Control 49
Command ASCII Command
(Host to Switcher)
Response
(Switcher to Host)
Additional Description
Input and Output Tie Commands (continued)
View Ties
View HDMI and audio output
tie
X@! X!]
OutX@
•
InX!
•
All]
View input tied to an HDMI
and audio output.
Verbose modes 2 and 3
View HDMI output tie
X@% or
X@&
X!]
OutX@
•
InX!
•
Vid]
View input tied to an HDMI
output.
Verbose modes 2 and 3
View audio output tie
X@$ X!]
OutX@
•
InX!
•
Aud]
View input tied to an audio
output.
Verbose modes 2 and 3
Input Configuration Commands
Input Name
Set input name
EX!,X$ NI} NmiX!,X$]
Set the name of an input.
View input name
EX!NI} X$]
NmiX!,X$]
View name of an input.
Verbose modes 2 and 3
HDCP Authorized Device
Set HDCP Authorized device
setting
EEX!*X^ HDCP} HdcpEX!*X^ ]
Set the HDCP Authorized
device setting for an input.
View HDCP Authorized device
setting
EEX! HDCP} X^]
HdcpEX!*X^]
View the HDCP Authorized
device setting for an input.
Verbose modes 2 and 3
Input HDCP Status
View input HDCP status
EIX! HDCP} X&]
HdcpIX!*X&]
View the HDCP status on
an input.
Verbose modes 2 and 3
View all input HDCP status
EIHDCP} X&
1
X&
2
...X&
n
]
HdcpI00*X&
1
X&
2
...X&
n
]
View the HDCP status for
all inputs.
n
= the maximum
number of inputs
Verbose modes 2 and 3
KEY:
X! = Input number
1 through <maximum number of inputs>
X@ = Output number
0 = untie (for ties if applicable)
HDMI output, 1 through <maximum number of outputs>:
DXP 42 — 1 or 2, DXP 44 and 84 — 1-4, DXP 88 — 1-8
X$ = Name
Up to 16 alphanumeric characters
X^ = HDCP Authorized device
0 = block HDCP encryption
1 = allow HDCP encryption (default)
X& = Input HDCP status
0 = no source detected
1 = source is HDCP compliant
2 = source is not HDCP compliant
