DXP HD 4K PLUS Series • SIS Configuration and Control 50
Command ASCII Command
(Host to Switcher)
Response
(Switcher to Host)
Additional Description
EDID Commands
NOTE: See EDID Minder on page3 for information on available EDID.
View EDID in Hex
ERX!EDID] X5)]
EdidRX5)]
View the EDID X5) in Hex
from input slot
X!
.
Verbose modes 2 and 3
View EDID native resolution
ENX!EDID] X5!]
EdidNX5!]
View the EDID native
resolution and refresh X5!
from input slot X!.
Verbose modes 2 and 3
Import EDID
EIX5@,X5#EDID] EIX5@] Import EDID table X5@ from
X5#.
Export EDID
EEX5@,X5#EDID] EEX5@] Export EDID table X5@ to
X5#.
KEY:
X! = Input number
1 through <maximum number of outputs>
X5) = EDID record
256 bytes of binary data in Hex
X5! = EDID resolution and rate
Native resolution and refresh rate from current EDID input assignment,
translated from Hex
X5@ = EDID slot
Default — 1080p @ 60 Hz
DXP 44 — 01-04 = input slot, 05-08 = automatically populated with
sink EDID from the output.
DXP 84 — 01-08 = input slot, 09-12 = automatically populated with
sink EDID from the output.
DXP 88 — 01-08 = input slot, 09-16 = automatically populated with
sink EDID from the output.
NOTE: See EDID tables for DXP HD 4K PLUS starting on page4
for lists of the available EDID.
X5# = EDID filename
EDID file name and path (can be a full path name). EDID file format is
.bin carrying 128 or 256 bytes of binary data.
