DXP HD 4K PLUS Series • Configuration Software 84
TCP/IP Panel
The TCP/IP panel connects PCS to a specific device through Ethernet.
Figure 43. TCP/IP Panel
1. Click the TCP/IP tab (see figure 43,
1
).
2. In the IP Address field (
2
), enter the IP address of the desired device.
3. If required, enter the device password in the Password field (
3
). Select the Show
Characters checkbox (see
5
) to display the password characters.
NOTES:
• The factory-configured passwords for all accounts on this device are initially set
to the device serial number. Passwords are case-sensitive.
• Performing a unit factory reset (entering an E ZQQQ
}
SIS command or
a mode 5 reset on page34 via the rear panel Reset button) removes the
serial number passwords, leaving the unit with no password.
4. In the Telnet Port field (
4
), enter the Telnet port of the desired device.
5. Click the Connect button (
6
). A new device tab opens.
