DXP HD 4K PLUS Series • Internal Web Page 87
Internal Web Page
This section provides procedures for accessing and using the DXP HD 4K PLUS internal
web page. Topics in this section include:
• Web Page Access
• Web Page Components - DXP 44, 84, 88
• Web Page Components - DXP 42
The internal web page displays information about the device and provides basic
configuration options. For more detailed configuration options, use SIS commands (see SIS
Configuration and Control starting on page39) or PCS (see Configuration Software
starting on page79, and the DXP HD 4K PLUS PCS Help File).
Web Page Access
To access the internal web page:
1. Connect the switcher to a LAN or WAN using the rear panel LAN connector (see
Connecting to the LAN Port on page10).
2. On a connected PC, open a web browser.
NOTES:
• The internal web page does not support compatibility mode in Microsoft
Internet Explorer
®
.
• If the Ethernet connection to the switcher is unstable, try turning off the proxy
server in the web browser.
3. Enter the IP address of the device in the browser Address field.
NOTE: The default IP address is 192.168.254.254.
4. Press the <Enter> key on the keyboard.
5. The switcher checks if the device is password-protected and performs one of the
following:
• If the device is not password-protected, the web page opens.
• If the device is password-protected, enter a user name (user or admin) in the User
Name field and the password in the Password field when prompted.
NOTE: The factory configured passwords for all accounts on this device have
been set to the device serial number. If the unit is reset to factory settings
(mode 5 reset or E ZQQQ
}
SIS command), these passwords are set to
no password. Passwords are case-sensitive.
6. Click the OK button.
