DXP HD 4K PLUS Series • SIS Configuration and Control 51
Command ASCII Command
(Host to Switcher)
Response
(Switcher to Host)
Additional Description
Output Configuration Commands
Output Name
Set output name
EX@,X$ NO} NmoX@,X$]
Set the name of an output.
View output name
EX@NO} X$]
NmoX@,X$]
View the name of an
output.
Verbose modes 2 and 3
Output Format
Set output format
EX@*X* VTPO} VtpoX@*X*] Set format X* of output X@.
View output format
EX@VTPO} X*]
VtpoX@*X*]
View the format of an
output.
Verbose modes 2 and 3
Output HDCP Mode
Set output HDCP mode to
Auto
ESX@*0HDCP} HdcpSX@*0] Set output X@ HDCP to
Auto.
Set output HDCP mode to On
ESX@*1HDCP} HdcpSX@*1] Set output X@ HDCP to
always encrypted.
View HDCP mode
ESX@HDCP} X1)]
HdcpSX@*X1)]
View the HDCP mode.
Verbose modes 2 and 3
Output HDCP Status
View output HDCP status
EOX@ HDCP} X1!]
HdcpOX@*X1!]
View the HDCP status of
an output.
Verbose mode 2 and 3
View all outputs HDCP status
EOHDCP} X1!
1
X1!
2
...X1!
n
]
View the HDCP status of all
outputs.
n
= maximum number of
outputs
HdcpO00*X1!
1
X1!
2
...X1!
n
]
Verbose modes 2 and 3
KEY:
X@ = Output number
HDMI output, 1 through <maximum number of outputs>:
DXP 42 — 1 or 2, DXP 44 and 84 — 1-4, DXP 88 — 1-8
X$ = Name
16 alphanumeric characters
X* = Output format
0 = pass-through (default)
1 = RGB (color quantization follows input)
2 = YUV 444 (color quantization follows input)
3 = YUV 422 (color quantization follows input)
X1) = Output HDCP mode
0 = auto (follow the input, default)
1 = on (always encrypt HDMI outputs)
X1! = Output HDCP status
0 = no sink connected
1 = sink connected but does not support HDCP
2 = sink connected and supports HDCP, but currently not encrypted
3 = sink connected, supports HDCP, and is currently encrypted
