DXP HD 4K PLUS Series • SIS Configuration and Control 52
Command ASCII Command
(Host to Switcher)
Response
(Switcher to Host)
Additional Description
Output Configuration Commands (continued)
HDMI Video Mutes
Set HDMI video mute
X@*X1@ B Vmt X@*X1@]
Set mute of an output.
NOTE: This command mutes both the HDMI video and the embedded audio.
View HDMI video mute
status
X@B X1@]
VmtX@*X1@]
View the mute setting of an
output.
Verbose modes 2 and 3
Set HDMI video mute to
all outputs
X1@*B VmtX1@]
Set mute of all outputs.
View all output mutes
EVM} X1$
1
X1$
2
...X1$
n
]
MutX1$
1
X1$
2
...X1$
n
]
View the mute status of
all outputs. n = maximum
number of outputs.
Verbose modes 2 and 3
Output 5 V Pulse
Pulse 5 V on HDMI
output
EPX@HPLG} HplgPX@]
Momentarily toggle the
HDMI 5 V off and on to
simulate an output X@ hot
plug event.
KEY:
X@ = Output number
HDMI output, 1 through <maximum number of outputs>:
DXP 42 — 1 or 2, DXP 44 and 84 — 1-4, DXP 88 — 1-8
X1) = HDCP mode
0 = auto (follow the input, default)
1 = on (always encrypt HDMI outputs)
X1@ = Video mute
0 = unmute, 1 = video mute, 2 = video and sync mute
X1$ = Output mute
0 = no mutes
1 = video mute (one or more outputs)
2 = audio mute (one or more outputs)
3 = video and audio mute (one or more outputs)
