DXP HD 4K PLUS Series • SIS Configuration and Control 47
X4*
= Data bits
7, 8 (default)
X4(
= Stop bits
1 (default), 2
X5)
= EDID record 256 bytes of binary data in Hex
X5!
= EDID resolution and rate Native resolution and refresh rate from current EDID
input assignment, translated from Hex
X5@
= EDID slot
(See EDID tables for
DXP HD 4K PLUS
starting on page4.)
Default — 1080p @ 60 Hz
DXP 42 — 01-04 = input slot, manually populated
via PCS
DXP 44 — 01-04 = input slot, 05-08 = automatically
populated with sink EDID from the output.
DXP 84 — 01-08 = input slot, 09-12 = automatically
populated with sink EDID from the output.
DXP 88 — 01-08 = input slot, 09-16 = automatically
populated with sink EDID from the output.
X5#
= EDID filename Name and path of the EDID file (can be a full path
name). The EDID file format is .bin, carrying 128 or
256 bytes of binary data.
Default = EXN_HDMI_1080p60_2Ch.bin
X5$
= MKP mode Volume steps:
1 = Set DXP to normal operation, 1-100 steps
(default).
2 = Set DXP to MKP volume control range, 1-64
steps.
NOTES:
• Entering the E ZQQQ} or E ZXXX} system reset command
resets the MKP mode to the factory default (mode 1).
• Affects all analog and S/PDIF audio outputs.
X5%
=
Subnet mask for CISG
command
A 2-digit code with optional leading zero.
