DXP HD 4K PLUS Series • SIS Configuration and Control 65
Command ASCII Command
(Host to Switcher)
Response
(Switcher to Host)
Additional Description
Input and Output Tie Commands (continued)
Input HDCP Status
View input HDCP status
EIX! HDCP} X&]
HdcpIX!*X&]
View the HDCP status on
an input.
Verbose modes 2 and 3
View all input HDCP status
EIHDCP} X&
1
X&
2
...X&
n
]
HdcpI00*X&
1
X&
2
...X&
n
]
View the HDCP status
for all inputs.
n
= the
maximum number of
inputs
Verbose modes 2 and 3
KEY:
X& = Input HDCP status
0 = no source detected
1 = source is HDCP compliant
2 = source is not HDCP compliant
Input Name
Set input name
EX!,X$ NI} NmiX!,X$]
Set the name of an input.
View input name
EX!NI} X$]
NmiX!,X$]
View name of an input.
Verbose modes 2 and 3
EDID Commands
NOTE: See EDID Minder on page3 for information on available EDID.
View EDID in Hex
ERX!EDID] X5)]
EdidRX5)]
View the EDID X5) in Hex
from input slot
X!
.
Verbose modes 2 and 3
Import EDID to user slot
EIX5@,X5#EDID]
EIX5@] Import EDID table X5@
from X5#.
Export EDID in binary format
EEX5@,X5#EDID]
EEX5@] Export EDID table X5@ to
X5#.
KEY:
X! = Input number
1 through 4
X5) = EDID record
128 or 256 bytes of binary data in Hex
X5! = EDID resolution and rate
Native resolution and refresh rate from current EDID input assignment,
translated from Hex
X5@ = EDID slot
Default — 1080p @ 60 Hz
NOTE: See EDID tables for DXP HD 4K PLUS starting on
page4 for lists of the available EDID.
X5# = EDID filename
EDID file name and path (can be a full path name). EDID file extension
is .bin and carries 128 or 256 bytes of binary data.
