DXP HD 4K PLUS Series • SIS Configuration and Control 67
Command ASCII Command
(Host to Switcher)
Response
(Switcher to Host)
Additional Description
Output Configuration Commands (continued)
Video Color Bit Depth
Set video color bit depth for an
output
EX@*X(BITD} BitdX@*X(]
Set the color bit depth for
output X@ to X(.
View color bit depth for an output
EX@BITD} X(]
View the bit depth for
output X@.
View color bit depth for all
outputs
EBITD} X(
1
•X(
2
] View color bit depth X(
for all outputs.
Signal Status
View signal status for all inputs
and outputs
EOLS} X2@
1
•X2@
2
•X2@
3
•X2@
4
*X2@
1
•X2@
2
]
Sig X2@
1
•X2@
2
•X2@
3
•X2@
4
*X2@
1
•X2@
2
]
View signal status X2@ of
all inputs and outputs.
HDCP Notification
Set HDCP notification
ENX2!HDCP} HdcpNX2!]
Set the HDCP notification
screen color to X2!.
View HDCP notification
EN HDCP} X2!]
View the HDCP
notification screen color.
KEY:
X! = Input number
HDMI input, 1 through <maximum number of inputs>:
X@ = Output number
HDMI output, 1 through <maximum number of outputs>:
DXP 42 — 1 or 2, DXP 44 and 84 — 1-4, DXP 88 — 1-8
X# = Hot plug status
0 = disable, 1 = enable
X( = Color bit depth
16 alphanumeric characters
X2! = HDCP notification screen
0 = black screen, 1 = green screen (default)
X2@ = Signal status
0 = no signal present, 1 = signal present
