Quantum Series Videowall Processing Systems • Installation and Maintenance 38
SDI input card connection example
14
SDI Source
SDI Source
HD-BNC to Standar
d
BNC Adapter Cable
HD-BNC to Standar
d
BNC Adapter Cabl
e
IN
3G/HD/SD-SDI
Figure 28. SDI Input Connection Example
