MPC-6000 / MPC-7000 / RND-2 INSTALLATION, OPERATION AND MAINTENANCE MANUAL
18
GENERAL SPECIFICATIONS
Operating specifications for the MPC-6000 / MPC-7000 / RND-2 are as follows:
Environmental
 Operating temperature - 32 - 120F (0 - 49C)
 Relative humidity - Up to 93% @ 90F (32C)
 To be installed in a dry protected environment only
Primary Supply
 Primary Input Voltage: 120 VAC (60 Hz) nominal
 MPC-6000 / RND-2 Maximum primary input current: 2.4A at 120 VAC
 MPC-7000 Maximum primary input current: 3.5A at 120 VAC
Secondary Power Supply
 24 volt lead-acid battery set
 Maximum Charge Voltage: 27.8 VDC
 Automatic Low Battery Disconnect - Disconnect Voltage: 18VDC
 MPC-6000 / RND-2 Maximum Charge Current: 1.7A (Minimum supervisory load)
 MPC-7000 Maximum Charge Current: 3.8A
 MPC-6000 / RND-2 Battery capacity: 7-38 AH (over 12 AH requires separate enclosure for
the batteries)
 MPC-7000 Battery capacity: 7-38 AH / 100 AH with optional Battery Charger, HBC-1 (over
18 AH requires separate enclosure for the batteries)
Auxiliary Power Outputs
 0.4A maximum per power output circuit
 Non-Resettable Power Output
Power limited
Voltage: 24 VDC nominal (31 VDC max.) filtered
Ripple: 1.5 VAC maximum (120Hz)
 Resettable Power Output
Power limited
Voltage: 24 VDC nominal (31 VDC max.) filtered
Ripple: 1.5 VAC maximum (120Hz)
The maximum cumulative available power output (including Auxiliary power and Serial
Interface power) is: 0.5A for MPC-6000/RND-2, 1.0A for MPC-7000.
Status Relays
 Three programmable relays
 One Non-programmable status relay
Status: Trouble
 Contact Rating:
1 A, 28 VDC maximum, resistive
 Form C Contact
