MPC-6000 / MPC-7000 / RND-2 INSTALLATION, OPERATION AND MAINTENANCE MANUAL
19
Notification Appliance Circuits
 Power limited
 Supervised
 Maximum Standby Current: 3.4mA
 Maximum Line Resistance @ 24V (nominal), unfiltered fullwave rectified
Current Draw Line Impedance
1.5A 2Ω
1.0A 3Ω
0.5A 6Ω
 Alarm Voltage: 24V, nominal (31V max.), unfiltered fullwave rectified
 Maximum Ripple: 16 VAC, 120Hz
 Use for special application only
 MPC-6000 Four Style Z/Class B or two Style Y/Class A circuits
 MPC-7000 Four Style Z/Class B or two Style Y/Class A circuits
Expandable to twelve Style Z/Class B or six Style Y/Class A circuits
 Maximum NAC Current: 1.5A / NAC circuit
MPC-6000 maximum total NAC current 3.0A (6.0A with optional NPE-1 transformer installed)
MPC-7000 Maximum total NAC current 5.0A (8.0A with optional NPE-1 transformer installed)
 Suitable for coded and non-coded application
 Refer to Appendix B to determine maximum synchronized notification appliances allowed
per NAC
Serial Interface Circuit
 Power limited
 Supervised
 (+, -) Voltage: 24 VDC nominal (31 VDC max.) filtered
 Maximum current: 0.40A at 24VDC
 (X+, X-) RS485 Voltage levels
 Maximum wire loop resistance: 11 ohms/line
 Communications Protocol: RS485
The maximum cumulative available power output (including Auxiliary power and Serial
Interface power) is: 0.5A for MPC-6000/RND-2, 1.0A for MPC-7000.
X1 Addressable Device Circuits
 Power limited
 Supervised
 Voltage: 24 VDC nominal (31 VDC max.) filtered
 Maximum Current (shorted): 0.375A
 Maximum wire loop resistance: 50 ohms (see graph in Appendix A on page 60)
 Style 4 or 6 circuit
 252 Addresses: detectors and modules max.
 MPC-6000: One circuit
 RND-2: No loop circuits
 MPC-7000: Two circuits expandable to four
