MPC-6000 / MPC-7000 / RND-2 INSTALLATION, OPERATION AND MAINTENANCE MANUAL
31
CONTROL UNIT INSTALLATION
PARTS SUPPLIED – MPC-6000 / MPC-7000 / RND-2
Enclosure Packages (Black or Red)
 Backbox Assembly
 Front Door Assembly with Window
 Inner Door Assembly
Electronics Package MPC-6000 / MPC-7000
MPC(6/7)-MB Main Board or MPC6-MB2 575-447328 Nameplate (MPC-7000)
MPC(6/7)-DB or MPC6-DB2 Display Board 906-220604 #6-32 x 1/4” Screws (17)
FDLC Loop Driver Board (2 with MPC-7000) 375-F943165 Spacers (8)
215-649113 Keyboard 140-820405 24K Ohm 1/2W Resistor (4)
330-944373 Thermal pad 140-050008-1 120 Ohm E.O.L. Resistor Assembly (2)
465-633943 Battery cable assembly 555-446055 Cable Assembly, 26 Pin
315-447309 Installation and Operation Manual 130-PM3223 Bridge Rectifier
315-447311 Operating Instructions 555-449116 Rectifier Cable Assembly
575-447310 Riser Diagram (MPC-6000) 899-G67197 #6-32 Keps Nuts (1)
575-447388 Riser Diagram (MPC-7000) 950-220604 #6-32 Nut (1)
575-447312 Nameplate (MPC-6000) 600-149373 Ground Wire Assembly
315-049403FA Programming Manual
Electronics Package2 MPC-6000
MPC6-MB2 Main Board 575-447328 Nameplate (MPC-7000)
MPC6-DB2 Display Board 906-220604 #6-32 x 1/4” Screws (17)
FDLC Loop Driver Board 375-F943165 Spacers (8)
215-649577FA Keyboard w/Releasing 140-820405 24K Ohm 1/2W Resistor (4)
330-944373 Thermal pad 140-050008-1 120 Ohm E.O.L. Resistor Assembly (2)
465-633943 Battery cable assembly 555-446055 Cable Assembly, 26 Pin
315-447309 Installation and Operation Manual 130-PM3223 Bridge Rectifier
315-447311 Operating Instructions 555-449116 Rectifier Cable Assembly
575-447310 Riser Diagram (MPC-6000) 899-G67197 #6-32 Keps Nuts (1)
575-447388 Riser Diagram (MPC-7000) 950-220604 #6-32 Nut (1)
575-447312 Nameplate (MPC-6000) 600-149373 Ground Wire Assembly
315-049403FA Programming Manual
Electronics Package RND-2
MPC6-MB Main Board or MPC6-MB2 950-220604 #6-32 Nut (1)
RND2-DB or RND2-DB2 Display board for RND-2 906-220604 #6-32 x 1/4” Screws (17)
575-447328 Nameplate (RND-2) 375-F943165 Spacers (8)
215-649113 Keyboard 140-820405 24K Ohm 1/2W Resistor (4)
330-944373 Thermal pad 140-050008-1 120 Ohm E.O.L. Resistor Assembly (2)
465-633943 Battery cable assembly 555-446055 Cable Assembly, 26 Pin
315-447309 Installation and Operation Manual 130-PM3223 Bridge Rectifier
315-447311 Operating Instructions 555-449116 Rectifier Cable Assembly
575-447310 Riser Diagram (RND-2) 899-G67197 #6-32 Keps Nuts (1)
600-149373 Ground Wire Assembly 315-049403FA Programming Manual
With NPE-1 Transformer Package
Transformer Assembly (120VAC) (2 required) (899-G67197) #6-32 Keps Nuts (2)
