Fargo DTC1250e - Page 27

DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0
November 2013 27
.
Step
Procedure
4
Lift up the Top Cover (D930294-01) to unsnap it from the module.
5
Open from front door.
Unsnap to loosen the 2 side tabs located on either side of the Lam Input Cover (D930290-01)
(It is not necessary to remove the Lam Input assembly to remove this front plate.)
Tilt the Lam Input Cover outward and slide UP to remove. NOTE: Tab Inserts
