DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0
November 2013 28
.
Step
Procedure
6
Open the Flipper Door. Remove the 2 screws (F000178) from the left side.
Picture shows door removed, but not necessary for Lamination cover removal.
7
Remove 1 screw (F000178) from the blue retainer clip (D930077).
Disconnect the Flipper Cable ( D930626)
