DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0
November 2013 78
.
Step
Procedure
4
Remove the Lead Screw Assembly by pushing UP and pulling OUT from the bottom at an angle.
Short Lead Screw D930155
Tall Lead Screw D930176
