FARMSCAN Jackal - Record Your Settings; Wiring Chart and Notes Section

AM-JACKAL-35 / JULY 2020
1
WRITE YOUR SETTINGS DOWN
WHEEL FACTOR: PULSES/M RATIO ___________________
IMPLEMENT WIDTH: ___________________
SPRAYER WIDTHS: SEC 1______ / SEC 2______ / SEC 3______
FLOW METER PULSES/LITRE RATIO: ___________________
USE THE CHART BELOW TO COLOUR CODE YOUR WIRING OR MAKE
NOTES AGAINST EACH PORT
A
BOTTOM ROW (GREEN PLUG)
B
TOP ROW (GREY PLUG)
A1
INPUT 1
B1
GROUND
A2
INPUT 2
B2
INPUT 7
A3
INPUT 3
B3
INPUT 8
A4
INPUT 4
B4
INPUT 9
A5
INPUT 5
B5
+12v OUT
A6
INPUT 6
B6
OUT 6
A7
GROUND
B7
OUT 5
A8
OUT 2
B8
OUT 4
A9
OUT 1
B9
OUT 3
A10
+12v In
+12v Battery
B10
RS232 TX
From GPS
A11
-Ve In
Ground / GND Battery
B11
RS232 RX
From GPS
