TST Assembly instructions FUF2 / FU3F -A/-C/-F
FEIG ELECTRONIC GmbH page 99 of 114 TST_FUxF-A-C-F_Montageanleitung_EN_15
Target speed for opening or closing move not reached
• Pre-limit switch reached before full speed was reached --> adjust ramps
• Current limiter prevents movement at full speed --> Inverter or motor working at performance limit --> adjust ramps or limiter
Measuring rotation factor not ready
Light line alignment completed successfully.
Light curtain light line alignment start
The second light line alignment wit normal drive speed is active
The resolution of the installed position encoder is too low to maintain robust light curtain operation.
More increments are required per door move. (Message only occurs when DIP-Switch is ON.)
In timer limit switch operating mode (typ. after power on) the door position is not available. Deadman speed is maintained until the
actual position becomes available again.
No door movement possible
The startup mode can be between 0 ... 31 seconds depending on the configuration.
Update File has the wrong format
The boot loader can be started, the controller expects the users input
Error reading USB stick (data storage)
• SPI or USB communication faulty
• USB stick write protected, memory full or formatted with an unknown file system
Log function is being initialized. The controller is halted until the initialization is complete.
The controller will shut down after a user reset (3-finger reset)
The Paramterfile can not be written because there were no free Directories found
The Paramterfile can not be written because the storage device is full
The Paramterfile can not be written because the storage device is write protected
The Paramterfile can not be written because the file is write protected
The Paramterfile can not be loaded because there was no file founded
The Paramterfile can not be loaded because the file is faulty or the key is unknown
