Feig Electronic TST FUZ2-CX User Manual

TST
Assembly instructions
FUZ2 -A/-B/-C/-CX/-G/-L
FEIG ELECTRONIC GmbH Page 87 of 96 TST_FUZ2-A-B-C-CX-G-L_Montageanleitung_EN_22.docx
No.
Description
Possible reason for error
F.860
Internal stationary unit error
Internal system fault on the stationary unit.
F.861
Internal mobile unit error
Internal system fault on the stationary unit.
F.862
Internal positioning error
Internal error of the positioning system. Presumably, the magnet is not attached properly.
F.867
Address of mobile unit not set
• The address of the mobile unit was not set so far
• The address has to be set in Parameter P.F07
• The address is written on a sticker on the mobile unit
F.910
No communication to
expansion board possible
• The communication to the expansion board is not possible
• No expansion board plugged in
• CAN Connection interrupted (Broken cable or no supply voltage for extension board)
F.911
ROM error on extension board
• Wrong Flash-Code
• Defective hardware or noise-saturated environment
F.912
RAM error on extension board
• Defective hardware or noise-saturated environment
F.920
Internal 2.5 V reference voltage
incorrect
• Hardware defect
F.921
Internal 15 V voltage incorrect
• Hardware defect
F.922
Emergency stop chain not
complete
Not all emergency STOP inputs are jumpered separately, although the entire emergency stop chain is jumpered
• Redundant check of the emergency stop chain triggered
F.925
Testing of the third shutdown
method failed
• defective hardware
F.928
Faulty input testing
• The testing of an cyclic tested input was not successful
• The connected device is not working
• The cable connection between the connected device and the controller is broken
F.92A
If the motor wiring test is
activated by P.112 the wiring
will be tested during system
tests.
• at least one motor cable is not or incorrectly connected
• Motor cable damaged
• Motor damaged
F.930
External watchdog incorrect
• Defective hardware or noise-saturated environment
F.931
ROM error
• Wrong EPROM-Code
• Defective hardware or strongly disturbed environment
F.932
RAM error
• Defective hardware or noise-saturated environment
F.933
Wrong frequency of CPU
• The clock frequency of the processor is wrong
F.935
Stack error
• User-Stack or System-Stack overflowed
• Possible software error due to recursive invocations (e.g. profile)
F.960
Faulty parameter checksum
• New EPROM version with different parameters
• Controller not yet initialized
F.961
Checksum from calibration
values etc.
• New EPROM version with different EEPROM structure
• Controller not yet initialized
