TECHNICAL DATA AND PERFORMANCES
Weights
Model 35.1 45.1 55.1 70.2 90.2 110.2 140.2 180.2 220.2 U.M.
Constructive configuration
Base version VB 724 807 874 1052 1220 1345 1820 1940 2010 kg
1 damper version V1 916 999 1066 1316 1484 1609 2148 2268 2338 kg
2 dampers version V2 927 1010 1077 1327 1495 1620 2170 2290 2360 kg
3 dampers version V3 1130 1213 1280 1577 1745 1870 2810 2930 3000 kg
Options and accessories
Internal fan
Reduced -3 -6 -2 -6 -17 -11 -22 0 -12 kg
Upsized 9 7 7 11 49 49 20 32 0 kg
Hot water coil
2 rows with pipes 31 35 38 39 44 49 70 80 90 kg
2 rows with 3 way valve 36 40 43 47 52 57 82 92 102 kg
3 rows with pipes 36 41 46 46 53 61 84 98 114 kg
3 rows with 3 way valve 41 46 51 54 61 69 96 110 126 kg
Electrical heater coil
Standard 21 21 21 37 37 37 74 74 74 kg
Upsized 34 34 34 52 52 52 104 104 104 kg
Condensing
gas heating module
Standard 270 270 270 402 402 402 720 720 720 kg
Upsized 275 275 275 442 442 442 800 800 800 kg
External coils protection grilles 8 8 8 16 16 16 32 32 32 kg
Droplets separator 29 29 29 41 41 41 78 78 78 kg
Rigid pocket filters 21 21 21 31 31 31 62 62 62 kg
Air flow silencers 27 27 27 36 36 36 - - - kg
The total weight of the unit, obtained summing up the weight of the unit in the chosen constructive configuration with the weight of
the selected accessories, is referred to the transport weight.
The weight of the accessories not present in the table reported above is negligible for the estimate of the total weight of the unit.
Model
Acoustic attenuation [dB] by octave bands [Hz]
63 125 250 500 1000 2000 4000 8000
35.1-45.1-55.1 3,0 4,0 16,0 19,0 25,0 24,0 16,0 12,0
70.2-90.2-110.2 3,0 2,0 15,0 14,0 16,0 18,0 13,0 9,0
Model
Sound power levels [dB] by octave bands [Hz]
Sound power
level
63 125 250 500 1000 2000 4000 8000 [dB] [dB(A)]
35.1 65,6 69,7 65,5 66,5 62,0 62,2 60,8 56,0 74 69
45.1 67,6 71,7 67,5 68,5 64,0 64,2 62,8 58,0 76 71
55.1 69,6 73,7 69,5 70,5 66,0 66,2 64,8 60,0 78 73
70.2 68,6 72,7 68,5 69,5 65,0 65,2 63,8 59,0 77 72
90.2 70,6 74,7 70,5 71,5 67,0 67,2 65,8 61,0 79 74
110.2 72,6 76,7 72,5 73,5 69,0 69,2 67,8 63,0 81 76
140.2 75,0 76,3 75,4 75,6 74,0 73,8 72,5 67,1 83 80
180.2 80,0 81,3 80,4 80,6 79,0 78,8 77,5 72,1 88 85
220.2 84,0 85,3 84,4 84,6 83,0 82,8 81,5 76,1 92 89
Return air fan noise levels
Air flow silencers acoustic attenuation
Reference conditions
Performances referred to units with V3 constructive configuration (3 dampers version) operating in cooling mode at NOMINAL conditions A35A27
with STANDARD air flow rate and available static head.
The sound power level is obtained starting from the data declared by the manufacturer of the fans.
