Ferroli RFA - Overall Dimensions

33
D
6
7
10
6
5551
150
2251
Q.E.
5
4
3
245 285
9
8
11
A2
Q.E.
245
5
4
3
13
11
6
7
10
9
8
E
5551
2251
D M 150
H
A4 N
6
106 B 106
39
39
5
53 A1 53
6
6
C
1
2
5
2
1
C
39
39
1
53 A1 53
106 B 106
6
6
35.1
45.1
55.1
70.2
90.2
110.2
VB
VB
con modulo
termico a gas
LEGEND
POS. DESCRIPTION
1 Refrigerant circuit inspection panel
2 Electrical box inspection panel
3 Internal fan inspection panel
4 External coils
5 External fans
6 Lifting points
7 Power supply holes
8 Internal coils condensate drain
9 Internal section condensate drain
10 External section condensate drain
11 Standard filters frame
12 External air cap
13 Gas heating module
14 Module for V1 and V2 constructive configurations
15 Module for V3 constructive configuration
35.1 - 45.1 - 55.1 70.2 - 90.2 - 110.2 UM
A1 1294 1894 mm
A2 2205 2370 mm
A3 2900 3065 mm
A4 2955 3255 mm
A5 3830 4265 mm
B 1188 1788 mm
C 1400 2000 mm
D 2735 2900 mm
E 2885 3050 mm
F 3535 3700 mm
G 4335 4500 mm
H 3815 4250 mm
I 4465 4900 mm
L 5265 5700 mm
M 930 1200 mm
N 465 600 mm
O 1265 1400 mm
VB
VB
with
condensing gas
heating module
A = Spring vibration dampers holes distance
TECHNICAL DATA AND PERFORMANCES
Overall dimensions
Models 35.1 - 45.1 - 55.1 - 70.2 - 90.2 - 110.2
