Festo CPV10 - Dimensions of the Fastening Holes

2. Fitting
2−7
Festo P.BE−CPV−EN en 0503g
Type of mounting rear
1
2
3
4
5
4
6
CPV10/14 CPV18
1
2
3
4
5
69 mm
1)
80 mm
1
)
92 mm
1)
14 mm (18 mm)
2)
10 mm x number of plates
(14 mm x number of plates)
2)
120 mm
15 mm
18 mm x number of plates
6 28 mm + 5 (36 mm + 5 )
2)
30 mm + 4
1) With CPV10/14 valve terminals the following applies:
 Dimension 1 for CPV10/14 valve terminals with IC connection.
 Dimension 2 for CPV valve terminal with MP, CP or AS−Interface connection
(without inputs/outputs).
 Dimension 3 for CPV valve terminal with DI connection.
2) Values in brackets for CPV14.
Tab.2/3: Dimensions of the fastening holes
